LLM1r6PKB

Post Oak Motherboards

AMD® Ryzen™ R1606G Processor, Long Life Mini  |

Made by Simply NUC

FLEXIBLE CUSTOMIZATION

The Simply NUC LLM1r6PK (code named Post Oak) is a mini computer built with an AMD® Ryzen™ Embedded R1606G processor, delivering innovation in a small space for embedded solutions. A wireless-AC card can be installed into one of two M.2 slots, leaving the other available slot for a lightning fast SSD. The bottom of the chassis is designed to accommodate mounting options including DIN rail and VESA plate. And there are board SKU options for embedded designs. Finally, whether it’s Windows® 10, Linux, or another OS, these systems are verified to run a wide range of operating systems so you can build the exact solution your clients want.

FEATURE RICH, MAINSTREAM PERFORMANCE

Post Oak is a mini computer that’s small in size with features that make it optimal for your embedded solutions. Its rich feature set makes Post Oak ideal for mainstream performance usages such as on-prem edge analytics. It supports a wide power supply range (12 to 19Vdc), offers two gigabit Ethernet ports, and three USB ports for I/O flexibility. And with two DisplayPort and one HDMI ports Post Oak has plenty of bandwidth for sophisticated digital signage usages.

BUILD EMBEDDED SOLUTIONS

Built to stand the test of time, Simply NUC is committed to supporting the manufacture and sales of Post Oak in the same form, fit, and function for seven years from launch (Aug 2020). Post Oak also comes in a board SKU option with a serial port header and two USB headers enabling other embedded usages such as kiosk, vending machines, and POS.

Long Life MotherboardsMotherboards

Form

2.25lbs | 5.5 × 5 × 4.5 inch
  1. AMD® Ryzen™ R1606G Processor
  2. AMD® Radeon™ Vega 3 Graphics
  3. 2x DDR4-2400 SODIMMs, 1.2V, 64GB max
  4. Wireless AC 802.11ac and Bluetooth (option)
  5. 1x front USB 3.1 type A ports
  6. Audio combo mic in/line out
  7. 12V – 19V power supply
  8. 2x Display Ports
  9. 1x HDMI 2.0 Port
  10. 2x rear USB 3.1 type A ports
  11. 2x 10/100/1000 Mbps RJ45 Ethernet ports

Specification

Processor

AMD® Ryzen™ R1606G Processor

Turbo boost

3.5 GHz Turbo

Cores / threads

Cores 2, Threads 4

Operating temp.

Ambient Operating Temp

Graphics

Max Resolution 4096x2304  |  AMD® Radeon™ Vega 3

Dimensions

2.25lbs | 5.5 × 5 × 4.5 inch

Memory

64GB

Storage

128GB M.2 SATA SSD

Networking

2x 10/100/1000 Mbps RJ45 Ethernet

Inputs

1x USB 3.1 type A port (front), 2x USB 3.1 type A (rear)

Configuration

Customise your NUC with the options below and they will all come pre-installed.

Product Build Options
+$0.00

This unit comes with one 4 GB DDR4 RAM card. Upgrade now and get a second card to increase your RAM as high as 64 GB at a discounted price.

Memory (RAM) *

+$0.00

M.2 Storage Option *

+$0.00

The operating system will be installed to the primary storage device. Contact Sales if you want your OS installed to a specific storage device or if you do not see your desired OS on this list.

Operating System *

+$0.00

8265 Wifi Option *

+$0.00

Power Supply *

+$0.00

This unit comes with 1 FREE year of Simply NUC support service, which includes part and labor support as well as outbound shipping. Optionally, this coverage can be extended to 3 or 5 years.

Extended Support Service *

+$0.00

HDMI Port Accessories

+$0.00

DP Port Accessories

+$0.00

Second DP Port Accessories

+$0.00

USB 3.1 Port Accessories

+$0.00

Mouse and Keyboard Pack

+$0.00

USB OS Restore Key
