Description

The NUC VGA LID is a USB based Adapter resolution up to 1920 x 1200. Provides alow latency connection and is “Plug-n-Play” between your NUC and a 2nd display.

Features

  • USB 2.0 specification compliant
  • Supports analog video output interface – VGA (D-sub 15pin)
  • Supports display resolution up to: 1920 x 1200 / 1920 x 1080 @ 32bit
  • USB Plug-n-Play compatibility
  • Identify Monitors
  • Multi-Display Control Panel
  • Shortcut to Windows Display
  • Display Modes: Primary/Extended/Mirror
  • Display Rotation:0°, 90°, 180°, 270°
  • Resolution to: 1920 x 1200 / 1920 x 1050

System Requirements

  • 1~2 Displays: CPU: Intel Single Core 1.5GHz or higher processor / RAM: 1GB memory or higher
  • 3~4 Displays: CPU: Intel Single Core 2.4GHz or higher processor / RAM: 1.5GB memory or higher
  • 5~6 Displays: CPU: Intel Dual Core 2.4GHz or higher processor / RAM: 2GB memory or higher
  • Playing DVD (720P) on the extending monitor: CPU: Dual Core processor with 2.4GHz or higher
  • Windows 8/8.1/10 (32-bit/64-bit)
  • Higher processor recommended for multi-displays and optimal performance

Specifications

  • Chipset: Trigger 2 T2-285A
  • Display Memory: 32MB (16MB x 2) DDR SDRAM
  • Host Interface: USB 2.0 NUC connector 1X4 1.25mm header.
  • Cable Length: 6″
  • Video Interface: D-sub 15pin (VGA) female
  • Power: Bus Powered
  • Current: ≦380 mA
  • Monitor Frequency: 60 Hz
  • Regulatory: CE, FCC, VCCI and C-Tick RoHS compliant
  • Operating Temp: 0 ~45°C
  • Storage Temp: -25~75°C
  • Humidity:85% non-condensing

Additional information

Weight .25 lbs
Dimensions 4 × 4 × 2 in
